expandable container house
Product Description
Product Description
A. Container house characteristics
1) High ability to assemble and disassemble more times,instal fast and low cost,ony need 3 persons can build a single box in just 30 minutes.
2) Earthquakeproof,heatproof and waterproof.
3) Cost saving and convenient transportation,and up to 14 sets of boxes can be transported by single vehicle.
4) Using life can up to 20 years
5) Good after sale services of installation, supervision and training.
6)Versatility:not ony can be used for accommodation,office or storate,but can be used for diffirent purposes such as showers,kitchens,bathrooms ect,whether it is tempory reisdence,construction site office,or outdoor work site.
B. Container house main structure and installation
Flat Pack Container is 6055x2990x2896mm with EPS/IEPS/Rock wool sandwich panel for wall & Glass wool for roof! 3 workers can install in 30 monutes. Can stack up to 3 floors! Electric wires runs over ceiling, including DB, breaker, power inlet & lights. Sockets & Switch included. Total-sealed-top & corner-draining system ensures no water leaking on roof top. Fully Welded Top frame + truss & Bottom frame + supports ensure product strength!
Standard
accessory
Roof System Q345B steel structure+ two-sides 0.45mm steel sheets + 70mm PU foaming integrated formed roof + Electrical tube and wiring +outdoor connection socket+distribution box
Chassis System steel struction chassis + 18mm thickness cement-fiber board + 2mm thickness PVC floor sheet (glass wool insulation for optional)
Permitted loading:>2.5KN/m2
Wall System 50/75/100mm EPS sandwich panel, rock wool sandwich panel,glass fiber sandwich panel, or PU sandwich panel
Door System Steel door / Fire-proof door / Sandwich panel door
Window System Aluminum alloy shutter window and the plastic-steel window, single or double glass
Floor System PVC, plywood or customized
Option Drainage system Provided plan, design and constrution
Electric system Provided plan, design and constrution
Technical
parameter Fire-proof grade A
Wind resistance grade 11
Earthquake resistance Grade 8
